Butterflies sit on your hand while you sip on your favorite drink, sending a message through sliding an interactive note across the bar to the stranger sitting on the other side of the bar, or a flowing water illusion allowing you to create ripples in the water. Arn’t these the experiences that you will like to see during your next visit to a club on Saturday night?


Introducing, MotionMagix™ Interactive Bar, a gesture based tracking technology by TouchMagix™. The Interactive Bar is an innovative product by TouchMagix Media that transforms a regular bar into an interactive platform to enable restaurant and bar patrons to network and engage in collaborative activities and create a great ambient experience. Integrated video-projectors project any content on the milky bar-surface. The intelligent tracking system of the Interactive Bar detects all objects touching the surface. This input is used to let the projected content interact dynamically with the movements on the counter. Objects can be illuminated at their position or virtual objects can be interacted with the hands.


This product can be installed across any hospitality venue as a tool to give its customers an avenue to engage and interact amongst themselves through next-gen motion and gesture technology. The state-of-the-art features of the Interactive Bar not only engage the audience, but create a memorable experience.
Specifications

Key Features

MotionMagix™ Interactive Bar

The hardware and software automatically adjusts to the changing ambient light conditions to provide accurate sensing in environments like malls, airports & open spaces

MotionMagix™ Interactive Bar

TouchMagix™ Creative Suite facilitates changing backgrounds, foregrounds, adding sounds and adjusting the physics of templates without any programming know-how

MotionMagix™ Interactive Bar

System can work with various display formats like Projector, LCD screens, LED screens, Digital Video Walls etc.

MotionMagix™ Interactive Bar

Correct projection skews, keystones to get a perfect image using inbuilt software

MotionMagix™ Interactive Bar
Set up 3 projectors on single Motionmagix™ system to create an edge-blended seamless display using built-in software
MotionMagix™ Interactive Bar

More than 100 templates, effects and applications which are easy to customize are available with the system.

MotionMagix™ Interactive Bar

Utilize clap sound detection with motion sensing to create richer experience.

MotionMagix™ Interactive Bar

Connect multiple motion sensors to create any size display areas. Upto 4 sensors can be connected on a single MotionMagix™ system. Multiple MotionMagix™ systems can be cascaded to expand further to any number of sensors

MotionMagix™ Interactive Bar

Our Technical Support engineers are available round the clock for your installation, content and technical queries

MotionMagix™ Interactive Bar
User analytics helps keep track of your campaign performance. Now you can count the number of interactions, average interaction time at hourly granularity. Download reports in CSV formats for detailed analysis in MS Excel
MotionMagix™ Interactive Bar

Automatically schedule projector to switch on and off at specified times to enable fully automated system operation at permanent installation sites

MotionMagix™ Interactive Bar

Remotely manage the system from anywhere in the world using web interface and remote control software
MotionMagix™ Interactive Bar

Create two independent experiences in the same vicinity using single CPU

MotionMagix™ Interactive Bar
Create interactive projections of any shape with inbuilt software
MotionMagix™ Interactive Bar
Customize templates and email mouse driven interactivity to your customers for approvals which can then be published on MotionMagix™ platform

Technical Specs

Detection method: MagixSense™ proprietary motion sensor.
3D Sensing Support: Using multiple MagixSense™ motion sensors
Interaction Modes: Hand detection and object detection mode with upto 50 concurrent users.
Display Support: Supports all Projectors, LCD Screens, LED Screens, Plasma, Digital Video Walls etc.
Detection Algorithms: Hand tracking, Object tracking
Sensing output format: TUIO or TouchMagix™ open XML format
Sensor Cable: 20M standard length. Special length upto 80M available on request.
Template Interface: TouchMagix™ Creative Suite. Supports TED editable template format and TCR locked publishing format.
SDK Interface: C/C++, .NET, Java, OpenGL, Direct3d, Unity3D, Flash Actionscript 2 / Actionscript 3
Operating System: Windows 7 32bit/64bit
Recommended PC: Graphics accelerated Dell Optiplex 780 DT, 2.8GHz Intel Quad Core, 4GB DDR3 RAM, Nvidia 210 GTX graphics card with CUDA support, Windows 7, 1333 MhZ FSB, 150 GB HDD or of better configuration
Power-supply: 220 V & 110 V
Sensor Positioning: A minimum of 3 ft and a maximum of 15 ft from detection area.
Mounting Method: Flexible pivoted ball socket clamp
Response time: < 15 milliseconds for light correction and interaction Calibration Drift: No drift
Display System Resolution: 1024 x 768, 1920 x 1080 (Full HD) or higher
Operating Temperature: 0 to + 40° C
Humidity: 10% to 90% non-condensing


Installation Examples

Any custom shape and size can be created for the Interactive Bar. Following are few examples for reference.

MotionMagix™ Interactive Bar - Top Projection, Top Detection

Top Projection, Top Detection
    MotionMagix™ Interactive Bar - Bottom Projection, Bottom Detection

Bottom Projection, Bottom Detection



Content

Content Samples

This showcase demonstrates some of the readymade effects available in our library which work on mouse motions. The mouse motion will be replaced by multi-point human gesture on the TouchMagix™ system. These templates can be easily customized by replacing the images and also the backdrops in them. TouchMagix™ provides a free open SDK and an interface into the system to allow 3rd party developers to develop content other than our standard templates and upload it to TouchMagix™ platform. Note: Some of the effects may run slow on machines without graphic accelerators or low RAM. These effects would run smoothly on TouchMagix™ Systems.
Starlet  Trail Boids Shadow Wings
Drift Trail Allure Trail Birds Trail
